Wago 857-811

Temperature signal conditioner for thermocouples; Current and voltage output signal; Configuration via software; Supply voltage: 24 VDC; 6 mm module width; light gray

Opis

PC configuration interface. For thermocouples of type J and K (E, R, N, S, T, B, C). Cold junction compensation (On/Off). Calibrated measurement range switching. Detects a sensor wire break. Detects measurement range underflow/overflow. Clipping capability for analog signal limitation to output end values. Safe 3-way isolation with 2.5 kV test voltage per EN 61140
