Wago 857-569

Power signal conditioner; Current and voltage input signal; Current and voltage output signal; Digital output; Configuration via software; Supply voltage: 24 VDC; 6 mm module width

Opis

Two isolated measurement inputs for both AC/DC voltages and currents. RMS measurement or arithmetic mean value. A digital signal output reacts to configured measurement range limits (on/off switching delay and threshold value switch function can be configured with up to two threshold values). Switchable filter function. Safe 3-way isolation with 3 kV test voltage per DIN EN 61010-1
