Produkt
IPF
PTSI0185
Poproś o ofertę
Prawa autorskie do obrazu: IPF
IPF PTSI0185
Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"
Opis
Parametry techniczne
| Design: | Cuboid |
| Housing coating: | Anodized |
| Material of optical surface: | Glass |
| Sensor width: | 140mm |
| Sensor length: | 25mm |
| Housing material: | Aluminum |
| Ambient temperature: | -10 - 50°C |
| Degree of protection (IP): | IP54 |
| Sensor height: | 80.5mm |
| Storage temperature: | -20 - 85°C |
| Voltage type: | DC |
| Number of pins: | 8 |
| Switching frequency: | 200Hz |
| Type of analog output: | 0 V ... 10 V |
| Type of switching function: | Normally closed contact/normally open contact |
| Standard for interfaces: | RS-232 |
| Measuring method for optical distance measurement: | Triangulation |
| Rated switching current: | 100mA |
| Scanning function: | Light-/dark-on mode |
| Reverse polarity protection: | yes |
| Hierarchical management: | Slave |
| Reichweite: | 425mm |
| Number of switching outputs: | 3 |
| Scanning principle: | Reflection sensor |
| Type of switching output: | PNP/NPN |
| Setting procedure: | Parameterization |
| No-load current: | 100mA |
| Supply voltage: | 24 - 24V |
| Short-circuit protection: | yes |
| Measuring range length: | 200 - 425mm |
| Absolute linearity deviation: | 0.12mm |
| Relative linearity deviation: | 0.12% |
| Laser protection class: | Class 2 |
| Wavelength of the sensor: | 670nm |
| Light beam form: | Line |
| Light spot range: | 3 - 3mm² |
| Light source: | Laser diode, red light |
| Resolution: | 60µm |
| Light spot, laser focus: | 4mm² |
| eClass 7.0: | 27270801 |
| eClass 7.1: | 27270801 |
| eClass 8.0: | 27270801 |
| eClass 9.0: | 27270801 |
| eClass 9.1: | 27270801 |
| ETIM-6.0: | EC001825 |
| ETIM-7.0: | EC001825 |
| IPF Product Group: | 705 |
| packaging dimensions: | 138.0mm x 95.0mm x 210mm |
| customs tariff number: | 85365019 |
| Zolltarifnummer: | 85365019 |
Parametry logistyczne
| ECCN: | |
| Kraj pochodzenia: | |
| EAN: | |
| Waga: | 0,00 kg |
| Długość: | 0,00 m |
| Szerokość: | 0,00 m |
| Wysokość: | 0,00 m |
