LLS-1121L-204
620-200-568
Operating principle: | Through-beam |
Light source: | Laser class 2, red 660 nm |
Housing size [mm]: | M12 |
Sensitivity adjustment: | 3-turn potentiometer |
Polarity: | PNP |
Output: | Dark-on |
Interface: | Standard output |
Connection: | M12 4-pin |
Supply voltage: | 10...36 VDC |
Switching frequency max. [Hz]: | 5000 |
Housing material: | Stainless steel V2A |
Temperature range: | -10...50 °C |
Enclosure rating (IP): | IP 67 |
ECCN: | |
Kraj pochodzenia: | |
EAN: | |
Waga: | 0,00 kg |
Długość: | 0,00 m |
Szerokość: | 0,00 m |
Wysokość: | 0,00 m |
