Belden
11265
RKF 30/13,5-05
Belden 11265
RKF 30/13,5-05
RKF 30/13.5-01 - 7/8" Power Receptacle Connector: Female, front mount, 3-pin(2+PE), silver housing, 230 V AC/DC, 12 A, 0.75 mm². RKF 30/11-01 - 7/8" Power Receptacle Connector: Female, front mount, 3-pin(2+PE), silver housing, 230 V AC/DC, 12 A, 0.75 mm²
Beschreibung
7/8" Power Receptacle Connector: Female, front mount, 3-pin(2+PE), silver housing, 230 V AC/DC, 12 A, 0.75 mm². Mini Receptacle connector, 7/8 inch A body, female 3-pole for front mounting, assembled stranded wire, potted with epoxy, chassis side thread PG11, screw connection (panel nut RSKF 11). Mini Receptacle connector, 7/8 inch A body, female 3-pole for front mounting, assembled stranded wire, potted with epoxy, chassis side thread PG13.5, screw connection (panel nut RSKF 13.5).
Downloads
Technische Daten
| brown: | green-yellow |
| Product Family:: | Power Connector |
| Product Sub Family:: | 7/8" Circular Connectors |
| Brand:: | Lumberg Automation |
| Connector Type:: | Receptacle |
| Type of Contact / Gender:: | female |
| Connector Design:: | Front mount |
| Number of Pins:: | 3(2+PE) |
| Shielding:: | Unshielded |
| Rated Voltage:: | 250 V AC/DC |
| Operating Voltage:: | 230 V AC/DC |
| Rated Current*:: | 12 A |
| Contact Resistance:: | ≤ 10 mOhm |
| Insulation Resistance:: | ˃ 10^9 Ohm |
| Ambient Temperature (Operation)*:: | -25 °C to +90 °C |
| Protection Degree / IP Rating**:: | IP68 |
| Pollution Degree:: | 3 acc. to DIN EN 60664-1 (VDE 0110-1) |
| Contact Base Material:: | CuZn |
| Contact Plating:: | Cu/Au |
| Contact Bearer Material:: | TPU |
| Contact Bearer Color:: | orange |
| Housing Material:: | CuZn, nickel-plated |
| O-Ring Material:: | Neoprene |
| Conductor Size:: | 0.75 mm² |
| Number of Wires:: | 3 |
| Conductor material:: | Cu |
| Wire Insulation Material:: | PVC |
| Insulated Wire Diameter:: | ø 2.40 mm |
| UL Cable Type:: | AWM: 1569 |
| RoHS Compliant:: | yes |
| Note Derating:: | * Notice derating |
| Protection Degree / IP Rating Note:: | ** only if mounted and locked in combination with Hirschmann / Lumberg Automation connector. |
| Note:: | Do not connect / disconnect under load. |
| 11264: | RKF 30/13,5-01 |
Logistische Daten
| ECCN: | |
| Ursprungsland: | CZ |
| EAN: | |
| Gewicht: | 0,04 kg |
| Länge: | 0,00 m |
| Breite: | 0,00 m |
| Höhe: | 0,00 m |
