Produkt
Weidmueller
9011990000
HTX 188
Poproś o ofertę
Prawa autorskie do obrazu: Weidmueller
Weidmueller 9011990000
HTX 188
Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"
Opis
Parametry techniczne
| Type: | HTX 188 |
| Order No.: | 9011990000 |
| Version: | Pressing tool, Crimping tool for contacts, Hexagonal crimp |
| GTIN (EAN): | 4008190026066 |
| Qty.: | 1 pc(s). |
| Width: | 200 mm |
| Width (inches): | 7.874 inch |
| Weight: | 420 g |
| Net weight: | 450 g |
| REACH SVHC: | Lead 7439-92-1 |
| Version: | Mechanical, without interchangeable inserts |
| Type of contact: | Coaxial connector |
| Diameter of outer sleeve: | 3.8 mm |
| Crimping type/profile: | Hexagonal crimp |
| Hexagon AF (A): | 3.25 mm |
| Hexagon spanner width (A 2): | 1.72 mm |
| Crimping station, width (B 1): | 10 mm |
| Crimping station, width (B 2): | 2.3 mm |
| Internal contact diameter (D): | 2 mm |
| ETIM 6.0: | EC000168 |
| ETIM 7.0: | EC000168 |
| eClass 9.0: | 21-04-38-11 |
| eClass 9.1: | 21-04-38-11 |
| eClass 10.0: | 21-04-38-11 |
| UNSPSC: | 56-11-15-08 |
| Type: | HTX 188 |
| Order No.: | 9011990000 |
| Version: | Pressing tool, Crimping tool for contacts, Hexagonal crimp |
| GTIN (EAN): | 4008190026066 |
| Qty.: | 1 pc(s). |
| Width: | 200 mm |
| Width (inches): | 7.874 inch |
| Weight: | 420 g |
| Net weight: | 450 g |
| REACH SVHC: | Lead 7439-92-1 |
| Version: | Mechanical, without interchangeable inserts |
| Type of contact: | Coaxial connector |
| Diameter of outer sleeve: | 3.8 mm |
| Crimping type/profile: | Hexagonal crimp |
| Hexagon AF (A): | 3.25 mm |
| Hexagon spanner width (A 2): | 1.72 mm |
| Crimping station, width (B 1): | 10 mm |
| Crimping station, width (B 2): | 2.3 mm |
| Internal contact diameter (D): | 2 mm |
| ETIM 6.0: | EC000168 |
| ETIM 7.0: | EC000168 |
| eClass 9.0: | 21-04-38-11 |
| eClass 9.1: | 21-04-38-11 |
| eClass 10.0: | 21-04-38-11 |
| UNSPSC: | 56-11-15-08 |
Parametry logistyczne
| ECCN: | |
| Kraj pochodzenia: | |
| EAN: | |
| Waga: | 0,45 kg |
| Długość: | 0,00 m |
| Szerokość: | 0,00 m |
| Wysokość: | 0,00 m |
