Produkt
Weidmueller
2602580000
ENERGY ANALYSER 550-24
Poproś o ofertę
Prawa autorskie do obrazu: Weidmueller
Weidmueller 2602580000
ENERGY ANALYSER 550-24
Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"
Opis
Parametry techniczne
| Type: | ENERGY ANALYSER 550-24 |
| Order No.: | 2602580000 |
| GTIN (EAN): | 4050118655841 |
| Qty.: | 1 pc(s). |
| Width: | 144 |
| Width (inches): | 5.669 inch |
| Height: | 144 mm |
| Height (inches): | 5.669 inch |
| Depth: | 81 mm |
| Depth (inches): | 3.189 inch |
| Net weight: | 1,080 g |
| Humidity: | 5...95 %, no condensation |
| Operating temperature, max.: | 55 °C |
| Operating temperature, min.: | -10 °C |
| Storage temperature, max.: | 70 °C |
| Storage temperature, min.: | -25 °C |
| Operating temperature: | -10 °C...55 °C |
| Storage temperature: | -25 °C...70 °C |
| REACH SVHC: | Lead 7439-92-1 |
| Current-measuring channels: | 4 + 2 |
| Distortion factor THD-I in %: | Yes |
| Harmonics, per order / current: | 1.-63. |
| Measuring accuracy for current: | 0.2 % |
| Rated current: | 1 / 5 A |
| Residual current measuring: | Yes |
| Distortion factor THD-U in %: | Yes |
| Four-wire system: | Yes |
| Harmonics, per order / voltage: | 1.-63. |
| Measurement range, voltage L-L, AC: | 720 V |
| Measurement range, voltage L-N, AC: | 417 V |
| Measuring accuracy for voltage: | 0.1 % |
| Quadrants: | 4 |
| Three-wire system: | Yes |
| Interface: | RS485: 9.6 – 921.6 kbps, Profibus DP, Ethernet, Web server/e-mail |
| Protocol: | Modbus RTU, Modbus-Gateway, Modbus TCP/IP, Modbus RTU over Ethernet, SNMP, Profibus DP V0, BACnet (optional) |
| Number of digital inputs: | 2 |
| Number of digital outputs: | 2 |
| Number of pulse outputs: | 2 |
| Temperature input: | Yes |
| Memory; minimum and maximum values: | Yes |
| Memory size: | 256 MB |
| Number of memory values: | 10,000 k |
| Update interval register: | 200 ms |
| Min. memory recording interval: | 1 s |
| Software: | ecoExplorer go® |
| Integrated logic: | Yes |
| Standards: | DIN EN 61326-1, DIN EN 61000-4-2, DIN EN 61000-4-3, DIN EN 61000-4-4, DIN EN 61000-4-5, DIN EN 61000-4-6, EN 61000-4-11, EN 55011, IEC 61010-1, IEC 61010-2-030, DIN EN 61000-4-8 |
| Measurement range, voltage L-N, AC: | 417 V |
| Measurement range, voltage L-L, AC: | 720 V |
| Surge voltage category: | 600 V CAT III |
| Voltage supply: | 48…110 V AC, 24…150 V DC |
| Three-wire system: | Yes |
| Four-wire system: | Yes |
| Quadrants: | 4 |
| Sampling frequency 50/60 Hz: | 20 kHz |
| Continuous measurements: | Yes |
| Effective value from the period (50/60 Hz): | 10 / 12 |
| Measurement result per second: | 5 |
| Residual current measuring: | Yes |
| Measuring accuracy for voltage: | 0.1 % |
| Measuring accuracy for current: | 0.2 % |
| Measurement accuracy for active energy (kWh, …/5 A): | Class 0.2S |
| Operating-hours counter: | Yes |
| Weekly time switch: | Yes |
| Current-measuring channels: | 4 + 2 |
| Clock: | Yes |
| Bimetal function: | Yes |
| Harmonics, per order / voltage: | 1.-63. |
| Harmonics, per order / current: | 1.-63. |
| Distortion factor THD-U in %: | Yes |
| Distortion factor THD-I in %: | Yes |
| Unbalanced: | Yes |
| Positive, negative and zero system: | Yes |
| Brief interruptions: | Yes |
| Sequence-of-events recorder function: | Yes |
| Surge voltage category: | 600 V CAT III |
| ETIM 6.0: | EC002301 |
| ETIM 7.0: | EC002301 |
| eClass 9.0: | 27-14-23-30 |
| eClass 9.1: | 27-21-03-01 |
| eClass 10.0: | 27-14-23-30 |
| ROHS: | Conform |
| Type: | ENERGY ANALYSER 550-24 |
| Order No.: | 2602580000 |
| GTIN (EAN): | 4050118655841 |
| Qty.: | 1 pc(s). |
| Width: | 144 |
| Width (inches): | 5.669 inch |
| Height: | 144 mm |
| Height (inches): | 5.669 inch |
| Depth: | 81 mm |
| Depth (inches): | 3.189 inch |
| Net weight: | 1,080 g |
| Humidity: | 5...95 %, no condensation |
| Operating temperature, max.: | 55 °C |
| Operating temperature, min.: | -10 °C |
| Storage temperature, max.: | 70 °C |
| Storage temperature, min.: | -25 °C |
| Operating temperature: | -10 °C...55 °C |
| Storage temperature: | -25 °C...70 °C |
| REACH SVHC: | Lead 7439-92-1 |
| Current-measuring channels: | 4 + 2 |
| Distortion factor THD-I in %: | Yes |
| Harmonics, per order / current: | 1.-63. |
| Measuring accuracy for current: | 0.2 % |
| Rated current: | 1 / 5 A |
| Residual current measuring: | Yes |
| Distortion factor THD-U in %: | Yes |
| Four-wire system: | Yes |
| Harmonics, per order / voltage: | 1.-63. |
| Measurement range, voltage L-L, AC: | 720 V |
| Measurement range, voltage L-N, AC: | 417 V |
| Measuring accuracy for voltage: | 0.1 % |
| Quadrants: | 4 |
| Three-wire system: | Yes |
| Interface: | RS485: 9.6 – 921.6 kbps, Profibus DP, Ethernet, Web server/e-mail |
| Protocol: | Modbus RTU, Modbus-Gateway, Modbus TCP/IP, Modbus RTU over Ethernet, SNMP, Profibus DP V0, BACnet (optional) |
| Number of digital inputs: | 2 |
| Number of digital outputs: | 2 |
| Number of pulse outputs: | 2 |
| Temperature input: | Yes |
| Memory; minimum and maximum values: | Yes |
| Memory size: | 256 MB |
| Number of memory values: | 10,000 k |
| Update interval register: | 200 ms |
| Min. memory recording interval: | 1 s |
| Software: | ecoExplorer go® |
| Integrated logic: | Yes |
| Standards: | DIN EN 61326-1, DIN EN 61000-4-2, DIN EN 61000-4-3, DIN EN 61000-4-4, DIN EN 61000-4-5, DIN EN 61000-4-6, EN 61000-4-11, EN 55011, IEC 61010-1, IEC 61010-2-030, DIN EN 61000-4-8 |
| Measurement range, voltage L-N, AC: | 417 V |
| Measurement range, voltage L-L, AC: | 720 V |
| Surge voltage category: | 600 V CAT III |
| Voltage supply: | 48…110 V AC, 24…150 V DC |
| Three-wire system: | Yes |
| Four-wire system: | Yes |
| Quadrants: | 4 |
| Sampling frequency 50/60 Hz: | 20 kHz |
| Continuous measurements: | Yes |
| Effective value from the period (50/60 Hz): | 10 / 12 |
| Measurement result per second: | 5 |
| Residual current measuring: | Yes |
| Measuring accuracy for voltage: | 0.1 % |
| Measuring accuracy for current: | 0.2 % |
| Measurement accuracy for active energy (kWh, …/5 A): | Class 0.2S |
| Operating-hours counter: | Yes |
| Weekly time switch: | Yes |
| Current-measuring channels: | 4 + 2 |
| Clock: | Yes |
| Bimetal function: | Yes |
| Harmonics, per order / voltage: | 1.-63. |
| Harmonics, per order / current: | 1.-63. |
| Distortion factor THD-U in %: | Yes |
| Distortion factor THD-I in %: | Yes |
| Unbalanced: | Yes |
| Positive, negative and zero system: | Yes |
| Brief interruptions: | Yes |
| Sequence-of-events recorder function: | Yes |
| Surge voltage category: | 600 V CAT III |
| ETIM 6.0: | EC002301 |
| ETIM 7.0: | EC002301 |
| eClass 9.0: | 27-14-23-30 |
| eClass 9.1: | 27-21-03-01 |
| eClass 10.0: | 27-14-23-30 |
| ROHS: | Conform |
Parametry logistyczne
| ECCN: | |
| Kraj pochodzenia: | |
| EAN: | |
| Waga: | 1,275 kg |
| Długość: | 0,00 m |
| Szerokość: | 0,00 m |
| Wysokość: | 0,00 m |
