Produkt
Weidmueller
1788340000
HDC 48B TOLU 1M40G
Poproś o ofertę
Prawa autorskie do obrazu: Weidmueller
Weidmueller 1788340000
HDC 48B TOLU 1M40G
Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"
Opis
Parametry techniczne
| Type: | HDC 48B TOLU 1M40G |
| Order No.: | 1788340000 |
| Version: | HDC enclosures, Size: 12, Protection degree: IP65, Cable entry from top, Plug housing, End-locking clamp, lower side, Standard, Size of cable entries: M 40 |
| GTIN (EAN): | 4032248205875 |
| Qty.: | 1 pc(s). |
| Width: | 90 |
| Width (inches): | 3.543 inch |
| Height: | 94 mm |
| Height (inches): | 3.701 inch |
| Depth: | 151 mm |
| Depth (inches): | 5.945 inch |
| Net weight: | 532 g |
| Limit temperature: | -40 °C ... 125 °C |
| REACH SVHC: | Lead 7439-92-1 |
| Cable entry: | w. threading |
| Height of housing B: | 94 mm |
| Total length housing: | 132 mm |
| Width housing C: | 90 mm |
| EMC housings: | No |
| Housing main material: | diecast aluminium |
| Material of locking element: | Stainless steel, rust-proof |
| Protection degree: | IP65 |
| Surface finish: | Powder coating |
| Tightening torque: | 1.2 Nm |
| Cable entry: | w. threading |
| Clamp version: | End-locking clamp |
| Design: | Standard |
| Design of housing: | Cable entry from top, Plug housing |
| Design of locking system: | End-locking clamp, lower side |
| Internal thread: | M 40 |
| Number of cable entry on top: | 1 |
| Number of cable entry sideways: | 0 |
| Size: | 12 |
| Size of cable entries: | M 40 |
| Suitable for ModuPlug®: | Yes |
| Tightening torque: | 1.2 Nm |
| Top part/bottom part/lid: | upper part |
| Type: | Plug |
| ETIM 6.0: | EC000437 |
| ETIM 7.0: | EC000437 |
| eClass 9.0: | 27-44-02-02 |
| eClass 9.1: | 27-44-02-02 |
| eClass 10.0: | 27-44-02-02 |
| UNSPSC: | 30-21-18-01 |
| ROHS: | Conform |
| Type: | HDC 48B TOLU 1M40G |
| Order No.: | 1788340000 |
| Version: | HDC enclosures, Size: 12, Protection degree: IP65, Cable entry from top, Plug housing, End-locking clamp, lower side, Standard, Size of cable entries: M 40 |
| GTIN (EAN): | 4032248205875 |
| Qty.: | 1 pc(s). |
| Width: | 90 |
| Width (inches): | 3.543 inch |
| Height: | 94 mm |
| Height (inches): | 3.701 inch |
| Depth: | 151 mm |
| Depth (inches): | 5.945 inch |
| Net weight: | 532 g |
| Limit temperature: | -40 °C ... 125 °C |
| REACH SVHC: | Lead 7439-92-1 |
| Cable entry: | w. threading |
| Height of housing B: | 94 mm |
| Total length housing: | 132 mm |
| Width housing C: | 90 mm |
| EMC housings: | No |
| Housing main material: | diecast aluminium |
| Material of locking element: | Stainless steel, rust-proof |
| Protection degree: | IP65 |
| Surface finish: | Powder coating |
| Tightening torque: | 1.2 Nm |
| Cable entry: | w. threading |
| Clamp version: | End-locking clamp |
| Design: | Standard |
| Design of housing: | Cable entry from top, Plug housing |
| Design of locking system: | End-locking clamp, lower side |
| Internal thread: | M 40 |
| Number of cable entry on top: | 1 |
| Number of cable entry sideways: | 0 |
| Size: | 12 |
| Size of cable entries: | M 40 |
| Suitable for ModuPlug®: | Yes |
| Tightening torque: | 1.2 Nm |
| Top part/bottom part/lid: | upper part |
| Type: | Plug |
| ETIM 6.0: | EC000437 |
| ETIM 7.0: | EC000437 |
| eClass 9.0: | 27-44-02-02 |
| eClass 9.1: | 27-44-02-02 |
| eClass 10.0: | 27-44-02-02 |
| UNSPSC: | 30-21-18-01 |
| ROHS: | Conform |
Parametry logistyczne
| ECCN: | |
| Kraj pochodzenia: | |
| EAN: | |
| Waga: | 0,748 kg |
| Długość: | 0,00 m |
| Szerokość: | 0,00 m |
| Wysokość: | 0,00 m |
