IPF AO000418
LED Surface area light, camera, 127x20x127mm, Polarity free red light, 10.8W, 120°, 24V DC, Connector M8 4pin, IP65, Aluminum+Acrylic glass
Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"
Opis
For any kind of inspection tasks with a camera sensor the lighting is essential, as only high-contrast images enable reproducible evaluations. Here the lighting has a decisive influence. The choice depends on different factors such as the distance to the test object, its size, the component criteria to be tested or the expected environmental conditions.
Parametry techniczne
| Width: | 127mm |
| Design: | Cuboid |
| Housing material: | Aluminum |
| Degree of protection (IP): | IP65 |
| Height: | 127mm |
| Length: | 20mm |
| Ambient temperature: | 10 - 50°C |
| Front screen material: | Acrylic glass |
| Protection class: | III |
| Voltage type: | DC |
| Type of electrical connection: | Connector M8 |
| Lamp power: | 10.8W |
| Number of pins: | 4 |
| Nominal supply voltage: | 24 - 24V |
| Radiation angle: | 120° |
| Number of LEDs: | 144 |
| Light source: | Polarity free red light |
| Light version: | Surface area light |
| eClass 7.0: | 27310204 |
| eClass 7.1: | 27310204 |
| eClass 8.0: | 27310204 |
| eClass 9.0: | 27310204 |
| eClass 9.1: | 27310204 |
| ETIM-7.0: | EC000348 |
| IPF Product Group: | 915 |
| shipping weight: | 0.55kg |
| packaging dimensions: | 230mm x 61.0mm x 290mm |
| customs tariff number: | 94054099 |
